Programmable High Speed Automatic Coil Winding Machine

(Model No.: AEH-01 & AEH-11)

Automatic coil winding machines are essential in various industries. We added the high-speed option and now our machines perform at four times the efficiency. Our high-speed winding machines are equipped with 16-Bit Microprocessors and stepper motors. In addition, they can wind coils at an incredible rate of 750 RPM.

DOWNLOAD

Easily Customizable Functions

What’s more, you can easily set up and program several functions like speed, number of turns, wire traversing functions, section winding, wire pitch, acceleration, and more.

Quick Installation & Set-up

Our automatic coil winding machines are designed for quick set-up. They can be installed and set-up in less than 8 hours. Time taken to program the various parameters depends on individual application specifications. However, programming time for each machine averages at 5 hours.

Automatic High Speed Winding Machines Common Applications

UPS
Inverters
C.T Coils
Transformer Coils
Wind Power Transformer Coils
Strap Winding For Heating Elements

High Speed Bench Winders: Product Features

Common features for models AEH-01 & AEH-11:

FEATURES	DETAILED INFORMATION
	AEH-01	AEH-11
WIRE DIAMETER	3.5 MM (.0039 - .138 IN) Size 38 - 7 AWG	5 MM (.0078 - .196 IN) Size 32 - 5 AWG
WINDING WIDTH	250 MM (9.84 IN)	500 MM (19.68 IN)
BOBBIN DIAMETER	280 MM (11.02 IN)	500 MM (19.68 IN)
DIMENSIONS W X D X H	890 X 400 X 370 MM (35.25 X 15.75 X 14.5 IN)	1300 X 600 X 450 MM (51.25 X 23.65 X 17.75 MM)
SPEED (MAX.)	750	500
	Attached speed knob allows for variable speeds. Specialized technology allows the speed to be changed while winding is in progress.
CONTROL SYSTEM	16 Bit Micro Controller
DISPLAY	Detailed information about the operation in progress. Includes number of turns among other vital information.
PROGRAMMING	Menu installed on top of the machine for easy access.
MEMORY	Can save up to 95 programs. Each program can consist of 9 sections.
ONLINE CORRECTION	Layer Stop, Brake, Winding Width, Wire Diameter, Speed, Spindle Locking, Guide Position
ANNUNCIATION	Over Speed, Layer Stop, Brake
COUNTING	Wire guide can be tracked with reference to winding direction.
PRODUCTION COUNTER	Built-in production counter.
SPEED INDICATION	Speed indication helps achieve high quality winding. Particularly helpful in high speed winding operations.
SECTION WINDING	With a total of 855 sections, each of the 95 winding programs allow for nine sections each.
WINDING DIRECTION	CCW
WINDING TYPE	Layer, Section, Bifilar, Tapping
CONTINUOUS DISPLAY	Program No., Section, Total Turns, Pitch, Width, Turns Wound
SPEED CONTROL	Both speed knob and speed indicator on panel allow for precise speed control.
ACCELERATION	Automatic start and stop. Gentle acceleration and deceleration.
PROGRAM PARAMETERS	The parameters related to winding operations are easily programmable.
STANDARD ACCESSORIES	Tail Stock, Wire Straightener wire Guide
APPLICATIONS	Power Transformers, UPS, CVT, HV Coils, PT, etc.
MANUAL BRAKE	Also provided is the option to manually activate the brake. This will allow better hold of the spindle. This option ensures a high amount of control.
TAPPING	Easy programming of taps – allows programming of up to 9 taps in each program. With 95 programs, this totals to 855 total taps.
POWER SUPPLY	Machines feature logic circuits and utilize SMPS power supply. This allows them to function continuously over a wide range of voltages.
LAYER STOP	Easily programmable to allow for several winding variations.
WIRE PITCH	Easily Programmable. Automatic soft start.
START FUNCTION	Programmed to start automatically. Soft start doesn’t jerk the machine or other equipment.
